Technical Specifications
Frame
Specialized A1 Premium Butted Alloy, 24 Trail Geometry, integrated down tube battery, internal cable routing, 148mm spacing, UDH compatible
Fork
RockShox Reba 26, 40mm offset, 100mm travel, 15x100mm spacing
Motor
New Specialized 1.2 SL Custom Rx Trail Tuned Motor
Battery
Specialized SL1-320, fully integrated, 320Wh
Charger
Custom charger, 48V System w/ SL system charger plug
UI Remote
Specialized MasterMind TCU, percentage of remaining charge, 120 possible display configurations, MicroTune assist adjustment, over-the-air updates, ANT+/Bluetooth®, w/Handlebar remote
Wiring Harness
Custom Specialized wiring harness
Crankset
SRAM X1 155mm
Pedals
VP-227, PP body w/ metal traction pins, Double sealed ball bearings
Chain
SRAM PC-1110, 11-speed w/ PowerLock
Cassette
SRAM PG-1130, 11-speed, 11-42t
Shift Levers
SRAM NX, 11-speed
Rear Derailleur
SRAM NX, 11-speed
Front Brake
SRAM Level T, Post Mount, 160mm
Rear Brake
SRAM Level T, Post Mount, 160mm
Rims
Specialized Alloy, Tubeless Ready, 25mm internal width, 32h
Front Tyre
Ground Control, Control Casing, 24x2.35
Rear Tyre
Ground Control, Control Casing, 24x2.35
Handlebars
Double-butted alloy, 9-degree backsweep, 31.8mm bar diameter, 660mm width
Grips
Specialized Trail Grips, lock-on
Saddle
Specialized bridge sport 130 mm
Seat Post
TranzX Dropper, 30.9mm, 80mm travel, 0mm offset, 315mm length
Seat Binder
Specialized Alloy, 34.9mm
Inner Tubes
Presta, 32mm valve
Chain Rings
SRAM X-Sync Eagle, 104 BCD, 32T
Front Hub
Specialized, sealed cartridge bearings, 15x110mm spacing, 32h
Rear Hub
Specialized, sealed cartridge bearings, 12x148mm thru-axle, 32h
Spokes
Stainless, 14g
Stem
Specialized, Forged alloy, 4-bolt, 6-degree rise, 35mm length
