Full Specification:
Frame:
M5 Alloy chassis and rear-end, asymmetrical design, 29/27.5" Trail Geometry with S-Sizing, SWAT™ Door integration, head tube angle adjustment, horst pivot BB adjustment, threaded BB, fully enclosed internal cable routing, 12x148mm dropouts, sealed cartridge bearing pivots, replaceable derailleur hanger, 150mm of travel
Rear Shock:
Rock Shox Super Deluxe Ultimate, Rx Trail Tune,RC2T Damper, Hydraulic Bottom Out control , S1:210x50mm, S2-S6:210x55mm
Fork:
RockShox Lyrik Ultimate, Charger 3 RC2 W/ButterCups, 15x110mm, 44mm offset, S1: 150mm of travel, S2-S6: 160mm of travel
Number of Gears:
12Gear Shifters:
SRAM GX, trigger, 12-speed
Chainset:
SRAM GX Eagle Alloy, DUB, 165/170/175mm, 32t
Chainrings:
32TRear Cassette:
Sram XG-1275, 12-speed, 10-52t
Chain:
SRAM GX Eagle, 12-speed
Rear Derailleur:
SRAM GX Eagle, 12-speed
Bottom Bracket:
SRAM DUB, BSA 73mm, Threaded
Pedals:
Not supplied
Rims:
Roval Traverse 29F/27.5R Alloy, 30mm inner width, hand-built, 2Bliss Ready
Front Hub:
Roval, sealed cartridge bearings, 15x110mm spacing, 28h
Rear Hub:
Roval DT Swiss 370, Ratchet LN, SRAM XD driver body, 12mm thru-axle, 148mm spacing, 28h
Front Tyre:
Butcher, GRID TRAIL casing, GRIPTON® T9 compound, 2Bliss Ready, 29x2.3"
Rear Tyre:
Eliminator, GRID TRAIL casing, GRIPTON® T7 compound, 2Bliss Ready, 27.5 x 2.3"
Brakes:
SRAM Code RS, 4-piston caliper, hydraulic disc, 200mm Centerline
Handlebars:
Specialized, 6061 alloy, 6-degree upsweep, 8-degree backsweep, 30mm rise, 780mm width
Handlebar Grips:
DeityStem:
Deity, 35.0mm
Saddle:
Bridge Comp, Hollow Cr-mo rails, 155/143mm
Seatpost:
OneUp, Dropper Post-V2, MMX lever, 34.9 (S1:120mm, S2/S3:150mm, S4: 180mm, S5/S6: 210mm)
Accessories:
Increased-volume SWAT™ Door integration with 22oz SWAT™ Bladder
Weight:
S4 - 15.55kg (34 lb, 4.5 oz)
