Technical Specifications
Frameset
Frame - FACT 11m carbon chassis and rear-end, asymmetrical design, 29 Trail Geometry, SWAT™ Door integration, flip chip Head Tube/Bottom Bracket adjustment, threaded BB, fully enclosed internal cable routing, 12x148mm dropouts, sealed cartridge bearing pivots, replaceable derailleur hanger, 130mm of travel
Seat Binder - Alloy, 38.6mm
Suspension
Rear Shock - FOX FLOAT DPS Performance, Rx Trail Tune, rebound and 3-position compression adjust, 190x45mm
Fork - FOX FLOAT 34 Rhythm, GRIP damper, two position Sweep adjustment, 15x110mm QR axle, 44mm offset, 140mm of travel
Cockpit
SeatPost - X-Fusion Manic, infinite adjustable, two-bolt head, bottom mount cable routing, remote SLR LE lever, 34.9, S1: 100mm, S2: 125mm, S3: 150mm, S4/S5: 170mm, S6: 190mm
Stem - Alloy Trail Stem, 35mm bar bore
Grips - Specialized Trail Grips
Saddle - Bridge Comp, Hollow Cr-mo rails, 155/143mm
Handlebars - Specialized, 6061 alloy, 6-degree upsweep, 8-degree backsweep, 30mm rise, 780mm width
Brakes
Front Brake - SRAM G2 RS, 4-piston caliper, hydraulic disc, 200mm
Rear Brake - SRAM G2 RS, 4-piston caliper, hydraulic disc, 180mm
Drivetrain
Rear Derailleur - SRAM GX Eagle, 12-speed
Shift Levers - SRAM GX, trigger, 12-speed
Cassette - Sram XG-1275, 12-speed, 10-52t
Chain - SRAM NX Eagle, 12-speed
Crankset - SRAM X1 Eagle, DUB, 32T, S1: 165mm, S2-S5: 170mm, S6: 175mm
Chainrings - 32T
Bottom Bracket - SRAM DUB, BSA 73mm, Threaded
Wheels & Tires
Front Hub - Alloy, sealed cartridge bearings, 15x110mm thru-axle, 28h
Rims - Specialized 29, hookless alloy, 30mm inner width, tubeless ready
Rear Hub - Alloy, sealed cartridge bearings, 148mmx12mm thru-axle, 28h
Front Tire - Butcher, GRID casing, GRIPTON® T9 compound, 29x2.3"
Spokes - DT Swiss Industry
Rear Tire - Purgatory, GRID casing, GRIPTON® T7 compound, 29x2.3"
Inner Tubes - Standard, Presta valve
Weight
Weight - 13.86kg (30 lb, 8.9 oz)
Weight Size - S4
